2.3/3/3.6/4.8/6.2M Flight Typed Dishwasher

Features and advantages

Hedging spray washing design makes the water curtain more evenly distributed and guarantees the washing effect;

Mechanical button design, preset two-speed washing speed, simple and convenient operation;

The photoelectric sensor detects the conveyor belt. When the tableware enters the machine, the equipment automatically starts and saves energy;

The casing is made of stainless steel SS304 and imported from Italy. The water pump is durable and powerful;

The laminated structure door can better reflect the humanized design and reduce labor intensity;

Safety protection device, except the emergency stop switch device, the conveyor belt will stop automatically if no one takes the bowl or the card.



Long dragon dishwasher fully embodies the advantages of modular combination

Customers can choose the combination of spray washing, washing and drying according to the washing volume, the cleanliness of the washing strips, and the type of tableware;

The length of inlet and outlet can be flexibly selected according to the environment, site conditions, washing speed, and the speed at which people place tableware;

The heating power can be selected according to the different inlet water temperature;

The speed of the conveyor belt can be adjusted tightly according to the washing weight or time.

Configure technical parameters

   AXE-L110J/L120J/L80J/L210J/L210JI
 Way to heat up  Electric Heating Dishwasher
 Power requirements  N~380V AC/50Hz/3PH
 Dimensions (mm) 2300x760x1510-6200x785x1725
 Area length (mm)  600/850/1200(Into the dish) +1100/1200/1800/2100 (Washing) +600/950/1500 (To close the dish)
 Machine entrance size (width & heightmm)  512/530×460
 Maximum washing capacity (dish/hour)  3600/4400/5200/6200
 Water consumption (l/h)  240
 Inlet water temperature (Celsius)  10~60
 Main wash temperature (Celsius)  60~65
 Spray temperature (degrees Celsius)  82~90
 Washing cycle (seconds)  Successive
 Total power (kw)  43/51/53.8/61.15/79.5
 Total current (A)  80/78/89/95/124
 Air switch rated power (A)  100
 Pre-allocation of seats (position)  900/1000/1300/1500
